1.>6000
Cycle Life@25°C
2.Multiple Safety Protection
Relay,Fuse,DC,Breaker
3.Smart BMS
Self-developed BMS
4.Parallel & Series
Assemblly Freely in series or Parallel Up to 16S 16P
5.Automatic Wake-up Function
Under off-grid System Environment
6.New&Old Batteries can be used in together
Connect in Parallel
7. Remote Monitoring
Self-developed APP
8. Voltage Balancing
Voltage Balancing between Battery Cells&Battery Pack
| Model | LFP-14336 | |
| Nominal Energy (Wh） | 14336 | |
Nominal Capacity (Ah) | 280 | |
| Nominal Voltage (V) | 51.2 | |
Charging/Discharging Cut-off Voltage | 58.4±0.3V/38.4±0.5V | |
| Opertation Voltage Range (V) | 48~56 | |
Recommend Charge Current (A) | 200 | |
Max. Continuous Charge Current (A) | 200 | |
Recommend Discharge Current（ A） | 200 | |
Max. Continuous Discharge Current (A) | 200 | |
Max. Connection Number | 16S16P | |
Operation Temperture (℃) | Charge | 0~55 |
Discharge | -20~55 | |
Operation Humidity | 20~80%RH(No condensing) | |
Protection Degree | IP21 | |
WIFI Frequency Range | 2400MHz~2483MHz | |
Over Voltage Category | II | |
Cooling Type | Natural convection | |
Dimension(mm) | 420*750*230 | |
Net Weight (kg) | 115 | |
Color | White | |
Case Material | Metal | |
Installation | Wall/Ground Mounting | |
Certification | Cell UL 1973/CE | |
Communication | CAN/RS485 | |
Cycle Life | >6000 Cycles（25℃) | |
Transportation | UN38.3 | |
Battery Type | LifePo4 Battery | |
Battery Protection | Over-current/Over-voltage/Short circuit/Under-voltage/Over temperature | |
| *Testing conditions based on temperature 25℃ at the beginning of life. *Total Energy/Usable Energy measured under specific conditions from CTE 0.2C CC-CV. | ||
